Old School, New Pics you havent seen
#12
perhaps it was a 6cahnnel, I know it was a helluva big amp back then, and I was fairly new to the scene then, but man was it loud. Got more old school pics? I will try to dig up some of my goodies, but probably wont be for a week or so
#17
#18
Into 4 ohms @ 12.5/14.4 VDC
50/80 WRMS x 2
Into 2 ohms @ 14.4 VDC
125 WRMS x 2
Into 1 ohm @ 14.4 VDC
150 WRMS x 2
Into .5 ohm @ 14.4 VDC
200 WRMS x 2
Bridged into 2 ohm @ 14.4 VDC
510 WRMS x 1
Bridged into 1 ohm @ 14.4 VDC
730 WRMS x 1
Frequency Response
+/-1dB from 20Hz to 20kHz
Signal to Noise Ratio
>100dB
Input Sensitivity
200 millivolts to 2 volts
Input Impedance
>30k ohms
Input Voltage Range
10.5 volts to 15.0 volts
Typical current draw at idle
3 amps
Minimum Impedance MPS series
1 ohm bridged/ .5 ohm stereo
